Brand: DMAR
Model: DMAR-04
Min. Order: 1
Application:

The machine is suitable for affusing a variety of cement grout. It can be used widely in anchor grouting of road, rail tunnels, subway,

hydropower stations, underground caverns. It also can be used in the curtain grouting project of soil for the dam, slope, soft rock reinforcement.

Characteristic:

1 Simple structure, light, wheel design and portable;

2 Way of working:grouting,stop and relief;

3 It has wide range of water-cement ratio and it can work continually. The suitable water-cement ratio is larger than 0.3;

4 Work Pressure can be adjusted according to project needs.

Performance:


Item Unit Index
displacement m3/h ≤0.4
water-cement ratio W/C ≥0.30
Grain size mm ≤1
Work pressure MPa ＜2.0
cubage of hopper L 15
weight KG 75
voltage V 380
power KW 0.75
L×W×H CM 125*32*75
