Brand: SVE
Model: wb-6
Min. Order: 1000PCS
MODEL WB-6 mmds downconveter RF input frequency 2,150 to 2,162MHz or 2,500 to 2,686MHz IF output frequency 116 to 128MHz or 222 to 408MHz L.O. frequency 1,838, 1,950 and 2,278MHz or as per requests L.O. frequency stability ±25kHz over temperature Noise figure 2.5dB±0.5dB Gain flatness ±1.5dB at 116 to 128MHz ±1.5dB at 222 to 408MHz Gain 36dB±2dB Image rejection > 80dB IF rejection > 80dB Output connector F-type female,75Ω Supply voltage +15 to +24 VDC Current 235 mA
