Brand: yuan
Model: YAT6802
Min. Order: 1对
Vertical round angle flap barrier is a high-tech product aimed at the pedestrian access intelligent management, which is a upgraded product based on intelligent tri-turnstile, swing barrier. This product is well-processed with full functions, high grade, and mainly used in high grade places such as top-grade community, intelligent mansion, hotel, subway, port, club etc. The product integrating with mechanism, electron, microprocessor and various identification technology is compatible with card reader devices such as IC card, ID card, bar code, fingerprint and so on. By configuring all kinds of identification devices and adopting reliable safeguard devices, alarm devices, direction indicator etc, it is able to achieve acess intelligentized control and management.
Functional features of standard product:

1. With function of self-examine and alarm, it is convenient for maintenance and use.
2. Being able to program running status by the small keyboard in the main board
3. Preventing pedestrians from being nipped and from hurt
Light and sound alarm funtion including the illegal in and the tail
4. Arms are automatically locked until opening signal is received.
5. Arms synchronization (adjustable)
6. Automatically reset function: It will automatically lock if the pedestrian hasn’t pass through the channel in the pre-set time after the opening. The passing time is adjustable.
7. Automatically open the gate when power off and automatically close when power on
8. Several card readers are attachable.
9. One direction or bi-direction are optional
10. It can be directly controlled and managed by remote control.
Extendable function:
Count
Length of framework and material of arm are optional.
Main structure and configuration
2 standard caseworks
2 stretchable arms (colours are optional)
2 main control boards
2 transformaers
2 electricmotors
2 sets of core and transmission parts
3 infrared devices
2 annunciators
3 direction indicators
Standard technology parameters
Framework material: State standard 304 grade stainless steel
Framework size: 600*300*1000(mm)
The length of arm:285mm
The widest breadth of the passage: 600mm
Weight: 60Kg
Driving eletricmotor: DC eletricmotor 24v
Normal life-span: 3million times
Communication interface: Rs485 standard Distance less than 1200metres
LED indicator: 2 card reader window: 4
Window for overhaul: 4
Transit speed: 30-40 persons/min
Time for opening or closeing: 1 seconds
Starting time after power is on: 3 secconds
Automatic reset time after fault: 10seconds
Working environment: indoor, outdoor( with a tent over)
Temperature: -10℃—— 50℃ Relative humidity: ≤90%
