Brand: yuan
Model: YAT6601N
Min. Order: 1
Access swing barrier, Luxury swing barrier
YAT6601N
YAT6601N is one kind of the no-obstacle fast-transit access control syetem with powerful functions, which is a ideal device to fulfill intelligentized access management. Because it has well solved the problem that the traditional tripot turnstile had, especially the low transit speed problem for people with luggage and the disable. It also permits bicycles to pass through and it’s a ideal upgraded product of tripot turnstile. What’s more, lights and lampshades are added to the main body, which makes the body more beautiful. All in all, it’s the best choice for such places as emporium, top-grade community and so on.
Main function: single direction induction ; Bi-direction ones can be extended to the same function of YAT6608
Technology Parameters:
Framework: 2.0 &1.0mm thickness of stainless steel shell
Framework size:
Main body:260*150*1150 The diameter of the pole:89mm
Lampshades, lights are intalled on the mainbody, which makes the mainbody more beautiful
Weight: 90Kg
The length of the swing arm: 500mm-830mm
The largest force the swing arm can surport: 30Kg
Swing arm running angle: 90degree
Swing direction: Single
Working power: AC220 ±10%V/50 ±10%HZ
Driving eletricmotor: DC eletricmotor 200w/24v
Input interface: touching signal or +12V signal or impulse signal of more than 100ms DC12V Driving current: > 10mA
Communication interface: RS485 standard Distance less than 1200metres
Transit speed: 40 persons/min(open often), 25-30 persons/min(close often)
Time for opening or closeing: 2-3seconds
Starting time after power is on: 3 secconds
Automatic reset time after fault: 10seconds
Working environment:
Indoor,outdoor (with a tent over)
Temperature: 10degree centigrade below—
50degree centigrade
Relative humidity: ≤90% never coagulated
2. Main function and characteristics
◇With function of self-examine and alarm,it is convinient for maintain and use.
◇Being able to program operation state by the small keyboard in the main board.
◇The mechanism is locked until a valid open signal is received.
◇Automatically reset function: It will automatically lock if the pedestrian hasn’t pass through the channel in the pre-set time after the opening. The passing time is adjustable.
◇Unit can be adjusted permanent open or close when power off to meet different needs.
◇The swing barrier automatically opens after power off and automatically closes when power on, which accords with fire-fighting.

Main structure and allocation:
main body 2
pole 4
baluster 2
Controllor 2
transformer 2
electricmotor 2
core and transmision parts 2
